Application 應用
v For heavy loading (high electric current) appliances such as: dry/steam iron, waffle maker, hot tray, electric stove, cooking oven, kitchen ware and heaters…etc..
v主要應用于大負載(大電流)器具上，如:干/蒸汽燙斗、烤餅機、電爐、電烤箱及其它廚房電加熱器具等…
Specifications 規格
v Function : v 功能 : | Single pole, the contact opens when the temperature is reached. 單體跳動特性，當溫度達到設定值后會自動斷開電路 |
v Standard Rating v 額定功率標準
| [ UL & CUL ] 125V AC 16A [ VDE & CE ] 250V AC 14A [ CQC ] 250V AC 14A |
v Number of Automatic Cycles for each Automatic Action: v 自動循環動作壽命: | [ UL & CUL ] 30,000 cycles [ VDE & CE ] 30,000 cycles [ CQC ] 30,000 cycles |
v Maximum Temperature : v 最高工作溫度 : | [All Standard] 250°C 所有標準 |
v Temperature Setting Range : v 溫度控制設定范圍 : | [All Standard] 0°C - 250°C 所有標準 |
v Tolerance of Operation Range : v 操作溫度公差范圍 : | ± 10℃ |
v Switching Differential : v 溫差： | 10 – 30K depending on mounting and design 依據安裝及設計定為10 – 30K不等 |
v Turning Range : v 旋轉角度 : | @ 300°D limited turning ranges possible 最大旋轉角度可控制在大約300° |
v Speed of Temperature Change : v 溫度變化速度 : | > 1K / min. 大于1K / min. |
Connections 連接方式
v Push-on terminal (For receptacle 4.8 mm or 6.3 mm) and M3.5 screw terminal is alternative.
v接線片有插線（配4.8或6.3規格線插）端子及鎖M3.5螺紋端子規格供選擇
Dimensions 尺寸
v Length of control shaft and angle of terminal plates is depended on customer requirement.
v轉軸長度及接線片角度可依據客戶要求來設定
Approval 認證
v UL File No.: E119937
v VDE Licence No.: 40015818
v CQC No.:CQC04002010127
